State-owned enterprises produce Processing seed gravity machine
2. Specifications of 5XZC series seed gravity separator:
1. Introduction of blowing type seed gravity separating cleaner
The 5XJC series seed gravity separator is a update of 5XJC series seed gravity separator, this machine adopt blowing air to achieve the purpose of gravity separation. is widely used in the seed processing and grain crop processing industries.
According to the principle of the segregation of particles and density in the process of fluidization of granular materials, the machine adjusts the technical parameters such as wind pressure and amplitude to make the materials exchange the positions and produce stratification. The parts of heavier specific gravity settles downwards, and the parts of lower specific gravity drifts upwards. After entering the dropping area, the materials of different types are discharged from different parts according to the requirements, which has achieved the purpose of selection.
3. Advantage of gravity separator:
|item ||5XZC-8A |
|Capacity (KG/H) ||5000 |
|Power(KW) ||13.32 |
|Selected rate ||98% |
|Crashing rate ||≤0.1% |
|Awn cleaning rate ||≥95% |
|Move speed(KM) ||≤10KM |
|Weight(KG) ||1800 |
|Dimensions(mm) ||3900*2300*2870 | 4. applications:
Advance gravity separator, blowing type supply much large wind power, easily for the grains separate the light gravity weight parts in the grains, like the moldy seeds, insect damaged seeds, broken seeds, and so on, to make sure the final grains much pure in quality.
The screen table adopt stainless steel material, the frame will be imported beech wood material, better shock absorption and much durable.
7 sets strong blowing fan, Strong and stable wind, good cleaning effect.
the gravity separator is suitable for all kinds grain seeds and crop seeds cleaning processing.
depend on the geometry size of different kinds of grains, we can equip different mesh size screens, thogh changing the screens, it can suitable for different grains, like maize, wheat, sesame, paddy, millet, cotton seeds, soya bean, sorghum, oat, ground nut, pumpkin seed, melon seed, sunflower seed, buckwheat, green bean, red bean, black bean, pea, chickpea, Alfalfa seeds, cassia seed, grass seeds and so on.
5XHC series air screen cleaning machine suitable for all kinds of grains. 5. Why choose Green Torch as your partner?
1. Since 1980, invested and established by Ministry of Agriculture of China, Guofeng Group Subsidiary, Green Torch is one of the earliest professional enterprise engaged in the research, development and production operation of grain seeds cleaning and processing machinery.
2. China state-owned Enterprises Invested and established by Ministry of Agriculture, perfect reputation in all clients , your trustable supplier in China.
Our machines have get SGS, ISO certificates and lots rewards.
3. Customized Service Qualified technicians team and workers, supply special design and perfect work depend on client needing
professional quality control department double inspect the machine before loading, make suare the machien pefect condition for you. , 2 years guarantee time, life time service for all our machines 6. About loading: For LCL, we will pack in durable wooden box package. Fix insed well to make sure the goods can arrive to your factory well. For FCL, we will make the 3D drawing for loading the goods in the container to make sure every part can be packed and loaded well.
4. Life time after service
7. FAQ: Q: What do you need to know for fast communication and quotation? A: It would be highly appreciated if you can provide details of your material specs, capacity and efficiency request, screen specification, motor power supply voltage and special brand needed. Q: Can you make the machines as per our special requirement? A: Yes, OEM/ODM service available. Q: What about the lead time? A: 10~45 workdays, depending on the type of machine and parts availability. Q: What is your payment terms? A: T/T, L/C, Western Union, Cash accepted. Usually 30% deposit for purchasing order, 70% balance paid before shipment. Q: How can you guarantee the quality? A: qualified quality control department make the Quality control by incoming material inspection, 100% in-production check and random check after packaging. Spare parts and technical solutions provided timely for machine failure. Q: How do we visit your company? A:Green Torch is located in Shijiazhuang City, Hebei Province, China. 1.You can fly from shenzhen/shanghai/hongkong to shijiazhuang air port directly 2.fly to beijing air port first then take high speed train to shijiazhuang city 3. We can go to Beijing airport to pick you up by High seed train to our city, and help you book the hotel in our city, if need will make the travel plan depend on your needing. 8. Welcome contact with us for more:
for more about our air screen cleaning machines, please contact with us freely, we will feedback to you within 12hours.
